Drive Cages & Hot-swap Modules / BPM-CEP725-HD
5.25" to 7x 2.5" 12Gb/s HDD SSD Hot-swap Rack
BPM-CEP725-HD — 5.25" to 7x 2.5" 12Gb/s HDD SSD Hot-swap Rack. Tray; 5.25" host 1; 3x9mm;4x7mm SAS 12G; 12Gb/s; Key Lock.
Product Overview
What the BPM-CEP725-HD is built for.
Industrial grade hot-swappable iStarUSA BPM-CEP725-HD mobile rack. Unique compact in size, high performance 7xSAS 12G interface. BPM-CEP725-HD is tough in strength, but flexible in functionality. LED indicator enables monitor power and hard drive activities. Security lock prevents intrusion and theft to the most important data. BPM-CEP725-HD mobile rack construct with quality and versatility. BPM-CEP725-HD is filed as an Anhsin Internal HDD Cage under Tray. Host opening: 5.25" Drives: 1. Hot-swap map: 3x9mm;4x7mm SAS 12G. Interface language on the original spec/feature list: 12Gb/s · SATA 6Gb/s · SAS. Security: Key Lock. Envelope (W×H×D): 5.74" x 1.64" x 6.45" · 145.8 mm x 41.7 mm x 163.8 mm.
Key Features
Engineered for reliability and integration.
- 7x SAS 12G (SAS 7pin) interface
- Fits 3x9mm;4x7mm SAS 12G SSD in a 5.25" space
- Support SAS 12G & SATA 6G speed
- Tray design with All Metal Parts (Industrial grade)
- Mechanical lock keeps HDD working securely
- LED indicator let users check working status any time
Specifications
Technical specifications.
| Model Number | BPM-CEP725-HD |
|---|---|
| Product Category | Drive Cages & Hot-swap Modules |
| Original Brand | Anhsin |
| Original Series | Internal HDD Cage |
| Hot-swap Type | Tray |
| Host Bay | 5.25" Drives: 1 |
| Drive Bays | 3x9mm;4x7mm SAS 12G |
| Interface | 12Gb/s · SATA 6Gb/s · SAS |
| Indicators | Power and HDD activity |
| Security | Key Lock |
| Material of Handle | Metal |
| Material of Main Chassis | Metal |
| Color of Main Chassis | Black |
| Dimensions | 5.74" x 1.64" x 6.45" · 145.8 mm x 41.7 mm x 163.8 mm |
| Certification | RoHS compliant |
| Drive Size Class | 2.5" 12Gb/s BP |
Applications
Where the BPM-CEP725-HD is deployed.
BPM-CEP725-HD SAS 12Gb/s expansion
Add 3x9mm;4x7mm SAS 12G at SAS 12Gb/s (SATA 6Gb/s where listed) inside 5.25" Drives: 1 for RAID/HBA storage growth.
BPM-CEP725-HD serviceable tray
Tray carrier lets a technician extract the drive without opening the host chassis — field-replaceable storage.
BPM-CEP725-HD locked drive bay
Original spec lists Key Lock — use in labs and shared racks where the drive must stay in the carrier.
BPM-CEP725-HD OEM / Design-In
Anhsin Internal HDD Cage under iStarUSA — bezel, fan, and envelope options follow the published spec; inquire for drawing-matched revisions.
Customization Options
Adapt the BPM-CEP725-HD to your program.
iStarUSA Design-In services cover mechanical, electrical, and lifecycle customization scopes.
BPM-CEP725-HD: tray / carrier finish and backplane connector matching
Lock hardware as specified (Key Lock) — cylinder/key matching on OEM lots
Bezel color, silk-screen, and logo
OEM labeling and long-lifecycle Anhsin / iStarUSA supply
