IPC Rackmount / FS-12241
2U Rackmount Chassis for Mini-ITX Systems
2U Mini-ITX with four 80 mm fans, two low-profile slots, two CF slots, and four 3.5" hot-swap trays.
Product Overview
What the FS-12241 is built for.
FS-12241 is the high-airflow 2U Mini-ITX: 17.50 inches deep, four 80 mm fans, two low-profile slots, two CF slots, two USB, two power switches, internal 2 × 2.5" plus 4 × 3.5", and four front 3.5" hot-swap trays. Flex ATX. Specify it when cooling count matters more than dual Mini-ITX nodes.
Key Features
Engineered for reliability and integration.
- 2U industrial rackmount for mini-itx motherboards
- Front accessible connectors: 2 x USB, 2 x CF slot, 4 x hot-swap trays
- Excellent cooling system with 4 x 80mm fans
- Board support: Mini-ITX
- Storage: Internal Drive Bay: 2 x 2.5" and 4 x 3.5" · Hot-swap: 4 x 3.5" HDD Tray (Front)
- Expansion: 2 x Low Profile
- Cooling: 4 x 80mm fan
- PSU: Flex ATX
Specifications
Technical specifications.
| Model Number | FS-12241 |
|---|---|
| Product Category | IPC Rackmount |
| Form Factor | 2U |
| Motherboard Support | Mini-ITX |
| Drive Bays | Internal Drive Bay: 2 x 2.5" and 4 x 3.5" · Hot-swap: 4 x 3.5" HDD Tray (Front) |
| Expansion Slots | 2 x Low Profile |
| Cooling | 4 x 80mm fan |
| PSU Support | Flex ATX |
| Front Panel | LED: 2 x Activity; 2 x Power · USB: 2 · Power SW: 2 |
| I/O Shield | Standard I/O (Not Included) |
| Material | Heavy duty cold-rolled steel |
| Finish | Black wet paint textured coat |
| Color | Black |
| Weight | 30 |
| Mounting | Optional Sliding rails |
| Memory Height | Accepts standard size |
| Compact Flash | 2 |
| Dimensions | 19.00" x 3.46" x 17.50" · 482.6 mm x 87.9 mm x 444.5 mm |
| Certification | RoHS compliant |
Applications
Where the FS-12241 is deployed.
Industrial Control
2U IPC chassis for PLC, SCADA, and line controllers.
Machine Vision Host
2 x Low Profile for capture and GPU/FPGA cards.
Factory Storage Node
Internal Drive Bay: 2 x 2.5" and 4 x 3.5" · Hot-swap: 4 x 3.5" HDD Tray (Front)
OEM/ODM Rack IPC
Bezel, PSU, and bay options under a FactorySmith drawing.
Customization Options
Adapt the FS-12241 to your program.
iStarUSA Design-In services cover mechanical, electrical, and lifecycle customization scopes.
Front-panel I/O and LED layout
Hot-swap bay count and backplane
PSU selection (Flex ATX / PS2 / DC)
Fan, filter, and rail kits
Color, silk-screen, and logo
Long-lifecycle FactorySmith program
Downloads
Documentation & drawings.
Two Ways to Buy
Order the standard model — or use it as a platform.
The FS-12241 is available both as a ready-to-ship standard product and as a starting point for OEM/ODM customization. Pick the path that matches your project.
Option A
Use as Standard Product
Order the FS-12241 with its published specifications. Ideal when you need a proven configuration, immediate quotation, and comparable datasheets against other models.
- Published specifications and datasheets
- Standard configuration, ready to quote
- Compatible with existing integrations
Option B
Use as Customizable Platform
Start with the FS-12241 and adapt it for OEM/ODM, Design-In, mechanical modification, or long-term supply programs. Our engineering team supports the full customization scope.
- OEM/ODM branding and mechanical modification
- Design-In engineering support
- Long-lifecycle and BOM stability planning
