IPC Rackmount / FS-13340
3U Rackmount Chassis for Micro-ATX Systems
3U microATX with four PCI slots, four 3.5" hot-swap, slim ODD, and mixed 60/80 mm fans on PSII.
Product Overview
What the FS-13340 is built for.
FS-13340 is a 3U microATX steel chassis: four PCI slots, PSII PSU, two 60 mm plus three 80 mm fans, slim optical, three internal 3.5", and four front 3.5" hot-swap trays. Published dimensions are 19.00 × 3.46 × 16.63 inches. It is the single-board 3U counterpart to dual-node FS-13280.
Key Features
Engineered for reliability and integration.
- 3U rackmount server chassis designed for Micro-ATX boards
- Supports: 4 x expansion slots, 4 x SATA2 drive trays
- DC cooling fan, Steel construction for industrial application
- Board support: Micro-ATX
- Storage: Internal Drive Bay: 3 x 3.5" HDD · Optical Drive Bay: 1 (Slim) · Hot-swap: 4 x 3.5" HDD Tray (Front)
- Expansion: 4 x PCI
- Cooling: 2 x 60mm and 3 x 80mm fan
- PSU: PSII
Specifications
Technical specifications.
| Model Number | FS-13340 |
|---|---|
| Product Category | IPC Rackmount |
| Form Factor | 3U |
| Motherboard Support | Micro-ATX |
| Drive Bays | Internal Drive Bay: 3 x 3.5" HDD · Optical Drive Bay: 1 (Slim) · Hot-swap: 4 x 3.5" HDD Tray (Front) |
| Expansion Slots | 4 x PCI |
| Cooling | 2 x 60mm and 3 x 80mm fan |
| PSU Support | PSII |
| Front Panel | LED: 1 x Activity; 1 x Power · USB: 2 · Power SW: 1 |
| I/O Shield | Standard I/O |
| Material | Heavy duty cold-rolled steel |
| Finish | Black wet paint textured coat |
| Color | Black |
| Weight | 30 |
| Mounting | Optional Sliding rails |
| Memory Height | Accepts standard size |
| Dimensions | 19.00" x 3.46" x 16.63" · 482.6 mm x 87.9 mm x 422.4 mm |
| Certification | RoHS compliant |
Applications
Where the FS-13340 is deployed.
Industrial Control
3U IPC chassis for PLC, SCADA, and line controllers.
Machine Vision Host
4 x PCI for capture and GPU/FPGA cards.
Factory Storage Node
Internal Drive Bay: 3 x 3.5" HDD · Optical Drive Bay: 1 (Slim) · Hot-swap: 4 x 3.5" HDD Tray (Front)
OEM/ODM Rack IPC
Bezel, PSU, and bay options under a FactorySmith drawing.
Customization Options
Adapt the FS-13340 to your program.
iStarUSA Design-In services cover mechanical, electrical, and lifecycle customization scopes.
Front-panel I/O and LED layout
Hot-swap bay count and backplane
PSU selection (Flex ATX / PS2 / DC)
Fan, filter, and rail kits
Color, silk-screen, and logo
Long-lifecycle FactorySmith program
Downloads
Documentation & drawings.
Two Ways to Buy
Order the standard model — or use it as a platform.
The FS-13340 is available both as a ready-to-ship standard product and as a starting point for OEM/ODM customization. Pick the path that matches your project.
Option A
Use as Standard Product
Order the FS-13340 with its published specifications. Ideal when you need a proven configuration, immediate quotation, and comparable datasheets against other models.
- Published specifications and datasheets
- Standard configuration, ready to quote
- Compatible with existing integrations
Option B
Use as Customizable Platform
Start with the FS-13340 and adapt it for OEM/ODM, Design-In, mechanical modification, or long-term supply programs. Our engineering team supports the full customization scope.
- OEM/ODM branding and mechanical modification
- Design-In engineering support
- Long-lifecycle and BOM stability planning
