Drive Cages & Hot-swap Modules / T5-SA
Trayless 5.25" to 3.5" SATA HDD Anti-vibration Hotswap Rack
T5-SA — Trayless 5.25" to 3.5" SATA HDD Anti-vibration Hotswap Rack. Trayless; Hotswap 3.5": 1 · 5.25" host 1; 3.5" SATA I/II; Key Lock; anti-vibration. Build-to-order on the original listing.
Product Overview
What the T5-SA is built for.
T5-SA is a mobile rack for use with 3.5" SATA I/II hard drive. The storage capacity of the hard drive is unlimited. The trayless and screwless design is for fast and easy installation. The anti-vibration air cushion design gives hard drive an extra protection from damage. Blue LED indicator enables monitor power and hard drive activities. Security key-lock prevents intrusion and theft to the most important data. T5-SA is filed as an Anhsin Internal HDD Cage under Trayless. Host opening: Hotswap 3.5": 1 · 5.25" Drives: 1. Hot-swap map: 3.5" SATA I/II. Security: Key Lock. Envelope (W×H×D): 5.75" x 1.57" x 7.48" · 146.1 mm x 39.9 mm x 190.0 mm. Availability on iStarUSA: Build-to-Order.
Key Features
Engineered for reliability and integration.
- Screwless and Trayless Design for fast HDD mounting
- Air Cushion for Anti-vibration
- Support SATA I/II Hard Drive
- Key Lock Prevents Theft or Removal During Operation
- Fit for Standard 5.25" Drive Bay
Specifications
Technical specifications.
| Model Number | T5-SA |
|---|---|
| Product Category | Drive Cages & Hot-swap Modules |
| Original Brand | Anhsin |
| Original Series | Internal HDD Cage |
| Hot-swap Type | Trayless |
| Host Bay | Hotswap 3.5": 1 · 5.25" Drives: 1 |
| Drive Bays | 3.5" SATA I/II |
| Indicators | Powr and HDD activity |
| Security | Key Lock |
| Material of Main Chassis | Frame: Metal/ · Front Panel: Plastic |
| Package Content | Mobile Rack, Manual, Keys, and Screws |
| Dimensions | 5.75" x 1.57" x 7.48" · 146.1 mm x 39.9 mm x 190.0 mm |
| Certification | RoHS compliant |
| Drive Size Class | 3.5" |
Applications
Where the T5-SA is deployed.
T5-SA SATA/SAS bay conversion
Convert Hotswap 3.5": 1 · 5.25" Drives: 1 into 3.5" SATA I/II hot-swap capacity for workstation and industrial storage.
T5-SA tool-less insert
Trayless path: the drive seats on the backplane directly, reducing parts count in dense 5.25" stacks.
T5-SA locked drive bay
Original spec lists Key Lock — use in labs and shared racks where the drive must stay in the carrier.
T5-SA OEM / Design-In
Anhsin Internal HDD Cage under iStarUSA — bezel, fan, and envelope options follow the published spec; inquire for drawing-matched revisions.
Customization Options
Adapt the T5-SA to your program.
iStarUSA Design-In services cover mechanical, electrical, and lifecycle customization scopes.
T5-SA: trayless backplane connector and bezel stack matching
Lock hardware as specified (Key Lock) — cylinder/key matching on OEM lots
Bezel color, silk-screen, and logo
OEM labeling and long-lifecycle Anhsin / iStarUSA supply
Two Ways to Buy
Order the standard model — or use it as a platform.
The T5-SA is available both as a ready-to-ship standard product and as a starting point for OEM/ODM customization. Pick the path that matches your project.
Option A
Use as Standard Product
Order the T5-SA with its published specifications. Ideal when you need a proven configuration, immediate quotation, and comparable datasheets against other models.
- Published specifications and datasheets
- Standard configuration, ready to quote
- Compatible with existing integrations
Option B
Use as Customizable Platform
Start with the T5-SA and adapt it for OEM/ODM, Design-In, mechanical modification, or long-term supply programs. Our engineering team supports the full customization scope.
- OEM/ODM branding and mechanical modification
- Design-In engineering support
- Long-lifecycle and BOM stability planning
