Industrial Rackmount Chassis / D-400
4U Compact Stylish Industrial Rackmount Chassis
A 4U rackmount chassis with 120mm high-airflow cooling, seven expansion slots, and mini-redundant PSU support — built for thermally demanding industrial and AI-edge builds.
Product Overview
What the D-400 is built for.
The D-400 is a 4U industrial rackmount chassis in the D Storm platform, offering the largest internal volume of the family. Combined with BPU or T Series cages it supports hot-swap storage of up to five drives, while seven expansion slots accommodate full-length add-on and accelerator cards. A 120mm plus 80mm fan arrangement delivers high airflow for tall CPU coolers and GPU cards, and PS2 or mini-redundant power supplies cover both cost-driven and uptime-critical deployments. The patented lockable aluminum bezel and removable washable filter keep it serviceable in industrial environments, and its generous volume makes it a common base for OEM/ODM appliance programs.
Key Features
Engineered for reliability and integration.
- Largest internal volume in the D Storm family — clearance for tall coolers and full-length accelerator cards
- High airflow from 1 × 120mm plus 1 × 80mm fans for thermally demanding builds
- Seven expansion slots for GPU, vision, motion, and network cards
- Supports PS2 or mini-redundant power supplies for uptime-critical systems
- Up to five drives total with optional BPU or T Series hot-swap cages
- Patented lockable aluminum front bezel (TW 200281 / 190240, CN 2L01259648.5) for custom branding
- Front-access 2 × USB 3.0 plus removable washable air filter for field service
- Power / HDD LEDs with power and alarm-reset switches for on-site diagnostics
Specifications
Technical specifications.
| Model Number | D-400 |
|---|---|
| Product Category | Industrial Rackmount Chassis |
| Form Factor | 4U |
| Motherboard Support | 12" × 9.6" — ATX, microATX |
| Drive Bays | 1 × 3.5" drive, 2 × internal 3.5", 4 × 5.25" drives (up to 5 drives with cages) |
| Expansion Slots | 7 |
| Cooling | 1 × 120mm + 1 × 80mm fans, removable & washable air filter |
| PSU Support | PS2 single or mini-redundant PSU |
| Front Connector | 2 × USB 3.0 |
| Security | Front bezel key lock |
| Material | 1.2mm SECC zinc-coated steel (Japan made), aluminum-alloy front bezel |
| Dimensions | 19.00" × 7.00" × 20.80" (482.6 × 177.8 × 528.3 mm) |
| Certification | RoHS compliant · HTS 8473.30.5100 · ECCN 4A994 |
| Indicators | Power, HDD, Temperature, Fan (Fan/Temp require TC-ISF08 sensor board) |
| Ordering Information | D-400 (black), D-400-BLUE, D-400-RED, D-400-SILVER |
Downloads
Documentation & drawings.
Applications
Where the D-400 is deployed.
Edge AI
Airflow and slot depth for accelerator cards.
Industrial PC
High-volume 4U control and inspection platforms.
Machine Vision
Multi-card vision and I/O configurations.
Data Center
Redundant-PSU 4U nodes for uptime-critical racks.
Storage Server
Up to five drives with hot-swap cages.
OEM/ODM Hardware Platform
Roomy base for branded appliance programs.
Customization Options
Adapt the D-400 to your program.
iStarUSA Design-In services cover mechanical, electrical, and lifecycle customization scopes.
Front Panel Customization
Mechanical Modification
Storage Configuration
Power Supply Options
Cooling Design
Branding / Labeling
Long Lifecycle Planning
Two Ways to Buy
Order the standard model — or use it as a platform.
The D-400 is available both as a ready-to-ship standard product and as a starting point for OEM/ODM customization. Pick the path that matches your project.
Option A
Use as Standard Product
Order the D-400 with its published specifications. Ideal when you need a proven configuration, immediate quotation, and comparable datasheets against other models.
- Published specifications and datasheets
- Standard configuration, ready to quote
- Compatible with existing integrations
Option B
Use as Customizable Platform
Start with the D-400 and adapt it for OEM/ODM, Design-In, mechanical modification, or long-term supply programs. Our engineering team supports the full customization scope.
- OEM/ODM branding and mechanical modification
- Design-In engineering support
- Long-lifecycle and BOM stability planning
Related Products
Explore adjacent options.
Design-In Center
Take D-400 into your next project.
Request a quotation on the standard SKU, or start a Design-In conversation around customization, lifecycle, and integration.
