IPC Rackmount / FS-12900
2U Rackmount Chassis for 2 × Mini-ITX Systems
Dual Mini-ITX 2U with six internal 3.5", front multi-I/O, and one expansion slot per system.
Product Overview
What the FS-12900 is built for.
FS-12900 is a dual Mini-ITX 2U with front multi-I/O: 16.60 inches deep, six internal 3.5", two expansion slots (one per system), two 8 cm fans, Flex ATX, 2×2 USB, 2×2 DB9 cutoffs, and two I/O shields (not included). It stores more internally than the hot-swap dual-node 2Us.
Key Features
Engineered for reliability and integration.
- 2U rackmount server chassis with dual mini-ITX system
- Design for easy access
- Multi I/O in the front panel
- Support 1x expansion slot for each system
- Board support: Mini-ITX
- Storage: Internal Drive Bay: 3.5"HDD x 6
- Expansion: 2
- Cooling: 8cm fan x 2
Specifications
Technical specifications.
| Model Number | FS-12900 |
|---|---|
| Product Category | IPC Rackmount |
| Form Factor | 2U |
| Motherboard Support | Mini-ITX |
| Drive Bays | Internal Drive Bay: 3.5"HDD x 6 |
| Expansion Slots | 2 |
| Cooling | 8cm fan x 2 |
| PSU Support | Flex ATX |
| Front Panel | LED: 2 x disk activity (Orange light) ; 2 x power on (Blue light) · USB: 2 x 2 · Power SW: 2 |
| I/O Shield | 2 (not included) |
| Material | Heavy duty cold-rolled steel |
| Finish | Black wet paint with texture coat |
| Color | Black. Customizable colour |
| Memory Height | Accept standard size |
| DB9 Cutoff | 2 x 2 |
| Dimensions | 19.00" x 3.46" x 16.60" · 482.6 mm x 87.9 mm x 421.6 mm |
| Certification | RoHS compliant |
Applications
Where the FS-12900 is deployed.
Dual-node Gateway
Two Mini-ITX systems in one rack unit for redundant or paired roles.
Split Workloads
Independent power switches and LED pairs where specified.
Industrial Storage Pair
Hot-swap trays shared or split across the two boards.
OEM Twin Cell
FactorySmith dual Mini-ITX program with Flex ATX or DC.
Customization Options
Adapt the FS-12900 to your program.
iStarUSA Design-In services cover mechanical, electrical, and lifecycle customization scopes.
Front-panel I/O and LED layout
Hot-swap bay count and backplane
PSU selection (Flex ATX / PS2 / DC)
Fan, filter, and rail kits
Color, silk-screen, and logo
Long-lifecycle FactorySmith program
Downloads
Documentation & drawings.
Two Ways to Buy
Order the standard model — or use it as a platform.
The FS-12900 is available both as a ready-to-ship standard product and as a starting point for OEM/ODM customization. Pick the path that matches your project.
Option A
Use as Standard Product
Order the FS-12900 with its published specifications. Ideal when you need a proven configuration, immediate quotation, and comparable datasheets against other models.
- Published specifications and datasheets
- Standard configuration, ready to quote
- Compatible with existing integrations
Option B
Use as Customizable Platform
Start with the FS-12900 and adapt it for OEM/ODM, Design-In, mechanical modification, or long-term supply programs. Our engineering team supports the full customization scope.
- OEM/ODM branding and mechanical modification
- Design-In engineering support
- Long-lifecycle and BOM stability planning
