IPC Rackmount / FS-19120
1.5U Mini-ITX Chassis
1.5U Mini-ITX in heavy CRS with up to two hot-swap trays and a single expansion slot.
Product Overview
What the FS-19120 is built for.
FS-19120 is the steel 1.5U Mini-ITX: 19.00 × 2.55 × 10.80 inches, Flex ATX, two 60 mm fans, one expansion slot (PCI-E 16x or 1x per the feature line), internal 2.5" or 3.5", and a 3.5" hot-swap tray. Front multi-I/O is the integration hook versus FS-19110’s shorter 10.02 inch body.
Key Features
Engineered for reliability and integration.
- 1.5U rackmount server chassis for mini-ITX system
- Design for easy access and system integration
- Mult I/O in front panel
- Support up to 2 hot-swap trays
- Support one PCI-E 16x or 1x expansion card
- Stylish design
- Board support: Mini-ITX
- Storage: Internal Drive Bay: 1 x 2.5"HDD or 1 x 3.5" · Hot-swap: 1 x 3.5 "HDD
Specifications
Technical specifications.
| Model Number | FS-19120 |
|---|---|
| Product Category | IPC Rackmount |
| Form Factor | 1.5U |
| Motherboard Support | Mini-ITX |
| Drive Bays | Internal Drive Bay: 1 x 2.5"HDD or 1 x 3.5" · Hot-swap: 1 x 3.5 "HDD |
| Expansion Slots | 1 |
| Cooling | 6cm fan x 2 |
| PSU Support | Flex ATX |
| Front Panel | LED: 2 x disk activity (Orange light) ; 2 x power on (Blue light) · USB: 2 · Power SW: 1 |
| I/O Shield | 1 |
| Material | Heavy duty cold-rolled steel |
| Finish | Black wet paint textured coat |
| Color | Black. Customizable colour |
| Memory Height | Accept standard size |
| Dimensions | 19.00" x 2.55" x 10.80" · 482.6 mm x 64.8 mm x 274.3 mm |
| Certification | RoHS compliant |
Applications
Where the FS-19120 is deployed.
Industrial Control
1.5U IPC chassis for PLC, SCADA, and line controllers.
Machine Vision Host
1 for capture and GPU/FPGA cards.
Factory Storage Node
Internal Drive Bay: 1 x 2.5"HDD or 1 x 3.5" · Hot-swap: 1 x 3.5 "HDD
OEM/ODM Rack IPC
Bezel, PSU, and bay options under a FactorySmith drawing.
Customization Options
Adapt the FS-19120 to your program.
iStarUSA Design-In services cover mechanical, electrical, and lifecycle customization scopes.
Front-panel I/O and LED layout
Hot-swap bay count and backplane
PSU selection (Flex ATX / PS2 / DC)
Fan, filter, and rail kits
Color, silk-screen, and logo
Long-lifecycle FactorySmith program
Downloads
Documentation & drawings.
Two Ways to Buy
Order the standard model — or use it as a platform.
The FS-19120 is available both as a ready-to-ship standard product and as a starting point for OEM/ODM customization. Pick the path that matches your project.
Option A
Use as Standard Product
Order the FS-19120 with its published specifications. Ideal when you need a proven configuration, immediate quotation, and comparable datasheets against other models.
- Published specifications and datasheets
- Standard configuration, ready to quote
- Compatible with existing integrations
Option B
Use as Customizable Platform
Start with the FS-19120 and adapt it for OEM/ODM, Design-In, mechanical modification, or long-term supply programs. Our engineering team supports the full customization scope.
- OEM/ODM branding and mechanical modification
- Design-In engineering support
- Long-lifecycle and BOM stability planning
Related Products
Explore adjacent options.
Product quotation
Request a quote for this model.
Standard or slightly modified builds of FS-19120 can be quoted on this page. For OEM/ODM manufacturing, system build and integration, or data center planning and deployment, start a project.
Start a project
Need more than a catalog quote for FS-19120?
This page quotes the model. OEM/ODM, system build and integration, and data center planning and deployment each have their own conversation.
