Drive Cages & Hot-swap Modules / T-C25HD-V
Custom Size Trayless 2.5" SATA 6 Gbps HDD SSD Hot-swap Anti-vibration Rack
T-C25HD-V — Custom Size Trayless 2.5" SATA 6 Gbps HDD SSD Hot-swap Anti-vibration Rack. Custom Size; 2.5" SATA I/II/III; SATA 6Gb/s; Key Lock; anti-vibration. Build-to-order on the original listing.
Product Overview
What the T-C25HD-V is built for.
T-C25HD-V is a stainless steel ultra-thin drive cage with anti-vibration mechanism design that takes custom size of space to give one 2.5" hotswappable and trayless SATA drive bay. The compact structure is perfect for OEM/ODM projects. T-C25HD-V is filed as an Anhsin Internal HDD Cage under Custom Size. Host opening: None. Hot-swap map: 2.5" SATA I/II/III. Interface language on the original spec/feature list: SATA 6Gb/s. Security: Key Lock. Envelope (W×H×D): 3.39" x 0.62" x 5.44" · 86.1 mm x 15.7 mm x 138.2 mm. Availability on iStarUSA: Build-to-Order.
Key Features
Engineered for reliability and integration.
- Support SATA I/II/III 6.0Gb/s Hard Drive
- Energy Saving on Using 2.5" HDDs or SSD
- LED Indicator for Power and HDD access
- Security Key Lock
- Stainless steel material to avoid rust problem after use
- Anti-vibration Design
- Support standard 2.5" HDD/SSD with 9.5mm thickness
- Custom size
Specifications
Technical specifications.
| Model Number | T-C25HD-V |
|---|---|
| Product Category | Drive Cages & Hot-swap Modules |
| Original Brand | Anhsin |
| Original Series | Internal HDD Cage |
| Hot-swap Type | Custom Size |
| Host Bay | None |
| Drive Bays | 2.5" SATA I/II/III |
| Interface | SATA 6Gb/s |
| Indicators | Power, HDD |
| Security | Key Lock |
| Material of Handle | Aluminum |
| Material of Main Chassis | Stainless Steel |
| Dimensions | 3.39" x 0.62" x 5.44" · 86.1 mm x 15.7 mm x 138.2 mm |
| Notes | custom size; will not fit standard 3.5" bay |
| Certification | RoHS compliant |
| Drive Size Class | 2.5" |
Applications
Where the T-C25HD-V is deployed.
T-C25HD-V SATA/SAS bay conversion
Convert None into 2.5" SATA I/II/III hot-swap capacity for workstation and industrial storage.
T-C25HD-V OEM custom envelope
Custom-size module for chassis that do not use a standard 5.25" or 3.5" optical bay — match the host opening on the drawing.
T-C25HD-V locked drive bay
Original spec lists Key Lock — use in labs and shared racks where the drive must stay in the carrier.
T-C25HD-V OEM / Design-In
Anhsin Internal HDD Cage under iStarUSA — bezel, fan, and envelope options follow the published spec; inquire for drawing-matched revisions.
Customization Options
Adapt the T-C25HD-V to your program.
iStarUSA Design-In services cover mechanical, electrical, and lifecycle customization scopes.
T-C25HD-V: custom envelope and mounting to the host opening (not a standard 5.25"/3.5" drop-in unless the drawing says so)
Lock hardware as specified (Key Lock) — cylinder/key matching on OEM lots
Bezel color, silk-screen, and logo
OEM labeling and long-lifecycle Anhsin / iStarUSA supply
Downloads
Documentation & drawings.
Two Ways to Buy
Order the standard model — or use it as a platform.
The T-C25HD-V is available both as a ready-to-ship standard product and as a starting point for OEM/ODM customization. Pick the path that matches your project.
Option A
Use as Standard Product
Order the T-C25HD-V with its published specifications. Ideal when you need a proven configuration, immediate quotation, and comparable datasheets against other models.
- Published specifications and datasheets
- Standard configuration, ready to quote
- Compatible with existing integrations
Option B
Use as Customizable Platform
Start with the T-C25HD-V and adapt it for OEM/ODM, Design-In, mechanical modification, or long-term supply programs. Our engineering team supports the full customization scope.
- OEM/ODM branding and mechanical modification
- Design-In engineering support
- Long-lifecycle and BOM stability planning
