IPC Rackmount / FS-11220
1U Dual Mini-ITX Chassis with Dual Hot-swap Trays
1U dual Mini-ITX with two power switches, four 40 mm fans, and two 3.5" hot-swap trays.
Product Overview
What the FS-11220 is built for.
FS-11220 is the dual-node 1U that behaves like two small servers: two Mini-ITX trays, two power switches, 2 × activity / 2 × power LEDs, four 40 mm fans, and two 3.5" hot-swap trays plus two internal 2.5". PSU is DC or Flex ATX in a 16.06 inch-deep steel chassis.
Key Features
Engineered for reliability and integration.
- 1U rackmount server chassis with 2 x Mini-ITX trays
- Both internal and external storage capacities; Supports 2 x SATA2 drive trays
- Board support: Mini-ITX
- Storage: Internal Drive Bay: 2 x 2.5" HDD · Hot-swap: 2 x 3.5" HDD Tray
- Cooling: 4 x 40mm fan
- PSU: DC Solution or Flex ATX
- Chassis: Heavy duty cold-rolled steel
- Envelope (W×H×D): 19.00" x 1.73" x 16.06"
Specifications
Technical specifications.
| Model Number | FS-11220 |
|---|---|
| Product Category | IPC Rackmount |
| Form Factor | 1U |
| Motherboard Support | Mini-ITX |
| Drive Bays | Internal Drive Bay: 2 x 2.5" HDD · Hot-swap: 2 x 3.5" HDD Tray |
| Cooling | 4 x 40mm fan |
| PSU Support | DC Solution or Flex ATX |
| Front Panel | LED: 2 x Activity; 2 x Power · USB: 4 (2 x 2) · Power SW: 2 |
| I/O Shield | Standard I/O (Not Included) |
| Material | Heavy duty cold-rolled steel |
| Finish | Black wet paint textured coat |
| Color | Black |
| Weight | 23 |
| Mounting | Optional Sliding rails |
| Memory Height | Accepts standard size |
| Dimensions | 19.00" x 1.73" x 16.06" · 482.6 mm x 43.9 mm x 407.9 mm |
| Certification | RoHS compliant |
Applications
Where the FS-11220 is deployed.
Dual-node Gateway
Two Mini-ITX systems in one rack unit for redundant or paired roles.
Split Workloads
Independent power switches and LED pairs where specified.
Industrial Storage Pair
Hot-swap trays shared or split across the two boards.
OEM Twin Cell
FactorySmith dual Mini-ITX program with Flex ATX or DC.
Customization Options
Adapt the FS-11220 to your program.
iStarUSA Design-In services cover mechanical, electrical, and lifecycle customization scopes.
Front-panel I/O and LED layout
Hot-swap bay count and backplane
PSU selection (Flex ATX / PS2 / DC)
Fan, filter, and rail kits
Color, silk-screen, and logo
Long-lifecycle FactorySmith program
Downloads
Documentation & drawings.
Two Ways to Buy
Order the standard model — or use it as a platform.
The FS-11220 is available both as a ready-to-ship standard product and as a starting point for OEM/ODM customization. Pick the path that matches your project.
Option A
Use as Standard Product
Order the FS-11220 with its published specifications. Ideal when you need a proven configuration, immediate quotation, and comparable datasheets against other models.
- Published specifications and datasheets
- Standard configuration, ready to quote
- Compatible with existing integrations
Option B
Use as Customizable Platform
Start with the FS-11220 and adapt it for OEM/ODM, Design-In, mechanical modification, or long-term supply programs. Our engineering team supports the full customization scope.
- OEM/ODM branding and mechanical modification
- Design-In engineering support
- Long-lifecycle and BOM stability planning
