IPC Rackmount / FS-1140
1U Chassis for 4 × Pico-ITX Boards
Four Pico-ITX boards in 1U — eight USB, four activity/power LED pairs, and four 3.5" hot-swap trays.
Product Overview
What the FS-1140 is built for.
FS-1140 is a 1U Pico-ITX quad: 19.00 × 1.73 × 12.52 inches, special I/O for Pico-ITX P720/P380/P840, eight USB (2×4), and per-system activity/power LEDs. Internal 2.5" bays trade against four internal CF readers; the list page also shows four front 3.5" hot-swap trays. Cooling is two 40 mm fans.
Key Features
Engineered for reliability and integration.
- 1U industrial rackmount platform accepting 4 x Pico-ITX? motherboard
- Front accessible connectors with 4 USB serial ports & 4 x Hot-swap HDD trays
- Board support: Pico-ITX
- Storage: Internal Drive Bay: 4 x 2.5" HDD (When CF card readers are not install · Hot-swap: 4 x 3.5" HDD Tray (Front)
- Cooling: 2 x 40mm fan
- Chassis: Heavy duty cold-rolled steel
- Envelope (W×H×D): 19.00" x 1.73" x 12.52"
Specifications
Technical specifications.
| Model Number | FS-1140 |
|---|---|
| Product Category | IPC Rackmount |
| Form Factor | 1U |
| Motherboard Support | Pico-ITX |
| Drive Bays | Internal Drive Bay: 4 x 2.5" HDD (When CF card readers are not install · Hot-swap: 4 x 3.5" HDD Tray (Front) |
| Cooling | 2 x 40mm fan |
| Front Panel | LED: 4 x Activity; 4 x Power (1/system) · USB: 8 (2x4) · Power SW: 1 |
| I/O Shield | Special I/O for Pico-ITX P720/P380/P840 |
| Material | Heavy duty cold-rolled steel |
| Finish | Anodized finish |
| Color | Black |
| Weight | 10 |
| Memory Height | Accepts standard size |
| Dimensions | 19.00" x 1.73" x 12.52" · 482.6 mm x 43.9 mm x 318.0 mm |
| Certification | RoHS compliant |
Applications
Where the FS-1140 is deployed.
Dense Edge Nodes
Four Pico-ITX systems in 1U with per-board USB and LEDs.
Appliance Farm
Hot-swap trays in front of four independent Pico boards.
OEM Multi-board 1U
Special I/O for Pico-ITX P720/P380/P840.
Factory Automation
Steel 1U for cabinet-dense control.
Customization Options
Adapt the FS-1140 to your program.
iStarUSA Design-In services cover mechanical, electrical, and lifecycle customization scopes.
Front-panel I/O and LED layout
Hot-swap bay count and backplane
PSU selection (Flex ATX / PS2 / DC)
Fan, filter, and rail kits
Color, silk-screen, and logo
Long-lifecycle FactorySmith program
Downloads
Documentation & drawings.
Two Ways to Buy
Order the standard model — or use it as a platform.
The FS-1140 is available both as a ready-to-ship standard product and as a starting point for OEM/ODM customization. Pick the path that matches your project.
Option A
Use as Standard Product
Order the FS-1140 with its published specifications. Ideal when you need a proven configuration, immediate quotation, and comparable datasheets against other models.
- Published specifications and datasheets
- Standard configuration, ready to quote
- Compatible with existing integrations
Option B
Use as Customizable Platform
Start with the FS-1140 and adapt it for OEM/ODM, Design-In, mechanical modification, or long-term supply programs. Our engineering team supports the full customization scope.
- OEM/ODM branding and mechanical modification
- Design-In engineering support
- Long-lifecycle and BOM stability planning
